internal external threading indexable insert carbide insert cnc tool holder

(0) 添加产品评论

Minimum Order Quantity

FOB Price

R25.0 / Piece

数量:: 库存 (全部: 1000 件数.)

所有货物价格都请参照最新价格

Specifications
产品细节

Quick Details

Place of Origin: Sichuan, China (Mainland)
Brand Name: Diamond
Model Number: SER2525M22
Application: Turning Tool
Carbide material: Imported
Testing Samples: FREE
Code: SER 2525M22
Product Name: carbide thread turning insert
OEM and ODM: Acceptable
Item: carbide insert cnc tool holder
Place of origin: Chengdu,China
usage: external and internal threading
name: cnc lathe tool holder
Certificate: ISO TUV SGS

Packaging & Delivery

Packaging Details:	1 pc in a plastic box, carton box outside
Delivery Detail:	5-7working days if have in stock

Specifications

carbide insert cnc tool holder:
1.special for external threading inserts
2.OEM&ODM acceptable.
3. Free samples: acceptable

Chengdu Diamond Tools Co., Ltd: 26 Years professional Manufactuer:

internal external threading indexable insert carbide insert cnc tool holder :

1.Application: Our carbide threading inserts cnc lathe tool holders are good for Low carbon steel, medium-carbon steel, High carbon steel, Alloy steel , Adjusting quality steel, Stainless steel, Cast steel, Cast iron,Aluminium alloy and copper alloy machining

2.Advantage Features for cnc lathe tool holder:

A. Full profile design ensures the precision of threads.

B. Rake face feature: Smooth rake face design makes the chip removal more fluency.

C. Cutting edge process feature: . Uniform horning cutting edge design ensures inserts with small cutting force .

Free samples:

cnc lathe tool holder will be provided free of charges for your trial testing, since seeing is believing.

Quality guarantee:

Strictly quliaty control processing in factory. and we promise to return back your payment or replace the products all at our costs in case of any problem.

Specifications of external threading cnc lathe tool holder:

No.	Model Number	h	a	b	L	f	insert	screw	wrench
1	SER/L1616H16	16	16	16	100	20	16ER/LΟΟΟ	M3.5	T15
2	SER/L2020K16	20	20	20	125	25
3	SER/L2525M16	25	25	25	150	32
4	SER/L3225P16	32	32	25	170	32
5	SER/L3232P16	32	32	32	170	40
6	SER/L2525M22	25	25	25	150	32	22ER/ LΟΟΟ	M4.0	T20
7	SER/L3225P22	32	32	25	170	32
8	SER/L3232P22	32	32	32	170	40
